9 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads

9 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads

A2 DTF Printer CMYK

Double EPSON I3200 A2 DTF Printer

Environmental Protection A2 Dtf Printer

Place of Origin:

China

Brand Name:

aiifar

Certification:

CE;EMC;ROHS

Model Number:

WP60-B1

Contact Us

Request A Quote
Product Details
Power:
1kw
Shaking Powder:
Motor Vibration, Automatic Powder Return-free
Heating Method:
Fast Constant Back Baking And Front Baking
Take-up And Feed Film:
Constant Tension Automatic Induction System
Operation Mode:
Manual Control/ Auto Control
Mesh Belt:
Drum Suction Operation Mesh Belt
Automatic Deceleration Of Film Cutting:
Prevent Deformation Of Heating Film
Method Of Dusting:
Constant Weight Automatic Sensing
Machine Weight:
240KG
Package Weight:
347KG
Package Dimensions:
181*94*136cm Cbm:2.31
Configuration:
With All-in-one Smoke Purifier
Nozzle Type:
2 Original Epson I3200
Priting Speed:
4 Pass 720*1200: High Speed Mode 15㎡/hour; 6 Pass 720*1800: HD Mode 10㎡/hour; 8 Pass 720*2400: HD Mode 8㎡/hour
Color Mode:
CMYK+LC+LM+Neon Y+Neon M+W
Print Format:
600mm-650mm
Media Transfer:
Damping Paper/ Tension Paper
Heating Equipment:
Front, Middle And Back Three-stage Heating
Power Supply:
110V/220V 50-60Hz
Working Environment:
Temperature 20-28℃ Humidity 70%
Ink Road System:
Automatic Ink Supply, Constant Pressure Circulation System
Weight:
160KG
Payment & Shipping Terms
Minimum Order Quantity
1
Price
negotiable
Packaging Details
Wooden packing
Delivery Time
60 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
10set week
Product Description

2023 A2 9 colors DTF printer CMYK+LC+LM+Neon Y+Neon M+W (double EPSON I3200 print heads) and shaker(integrated smoke filter)



Description of DTF Tshirt Printer machine

What is DTF Tshirt Printer machine? DTF is a name of a printing method of direct-to-film, which allows you to print a design on a film and transfer it directly to the intended surface, such as fabric. The key reason why the DTF printer is gaining prominence is the freedom it gives you to choose almost any surface for printing.



DTF is a revolutionary new printing technique, it's more affordable and accessible compared to DTG, screen printing, or laser white toner transfers.



DTF required a modified printer, Special DTF ink, Special DTF powder and DTF transfer film. With DTF you can transfer to 100% cotton shirts without pre-treatment, saving a lot of money and time. DTF uses a lot less ink than DTG. DTF is strong washable and it feels a lot better to the touch.



Product Features:



1. The all-in-one purifier can filter all smoke, meets environmental protection standards, and can be used in shopping malls, shops, indoors.
2. Intelligent touch control screen, automatic mode completely frees hands, one person can operate 3 machines, saving labor.
3. The upper and lower double rows of high-efficiency heating lamps, combined with a unique intelligent heating solution, can save 30% of power consumption.
4. High frequency powder shaking device, less noise, better powder shaking effect, so that the final pattern will not appear white edge.

5. The patented suciton roller design greatly enhances the suction force to ensure smooth film transportation and good temperature control which greatly extends the life of the blower.

6. Tension take-up device, the winding is more neat. Improved automation, a roll of film can be completely printed without operation.



Specification of DTF Film Printer



60cm DTF machine
Nozzle Type 2 original Epson I3200
Printing Speed 4 pass 720*1200 :High speed mode 15m²/hour
6 pass 720*1800
:HD mode 10m²/hour
8 pass 720*2400
:HD mode 8m²/hour
Color Mode CMYK+LC+LM+Neon Y+Neon M+W
Print Format 600mm-650mm
Media Transfer Damping paper/tension paper
Heating Equipment Front, middle and back three-stage heating
Power Supply 110V/220V 50-60Hz
Power 1kw
Working Environment Temperature 20-28 Humidity 70%
Ink road system Automatic ink supply,
Constant pressure circulation system
Weight 160KG
Package Dimensions 181*94*136cm cbm:2.31


Specification of DTF Powder Shaker



Shake powder machine
Power ≈3KW
Shaking Powder Motor vibration, automatic powder return-free
Heating Method Fast constant back baking and front baking
Take-up and Feed film Constant tension automatic induction system
Operation Mode Manual control/ Auto control
Mesh Belt Drum suction operation mesh belt
Automatic Deceleration of Film Cutting Prevent deformation of heating film
Method of Dusting Constant weight automatic sensing
Machine Weight 240KG
Package Weight 347KG
Package Dimensions 193*114.5*110.5cm cbm:2.44
Configuration With All-in-one smoke purifier


Feature&Advantage Of DTF powder shaker

  • Intelligent PCL control panel: Simple operation and automatic production;
  • Integration smoke purifier: More environmentally and has better effect for purifying the smoke;
  • The sucction roller design: Ensure smooth film transportation;
  • Weight sensor fro powder release: the automation of the process can be further improved, and the manual workload can be reduced. The preheating system has a smoke exhaust function to prevent powder sticking;
  • High frequency powder removal: More quietly while it working, the white powder spots on the pattern on the dark background clothing can be removed;
  • Heating lamp: Up and down two sides, heaitng more efficiently and make the film evenly.
  • Intelligent heating control: Save 30% energy compare with other company
  • Constant tension paper system: Automatic collect the film without any operating
  • coolling the film
  • powder collecting box
  • Motherboard 3 years warranty

 Advantage of DTF powder shaker

  • More cost effective
  • 2 Epson i3200
  • Stable printing result
  • Technical team support
  • Multiple DTF inks available, including Fluorescent and spot color

How WE HELP OUR CLIENTS SAVE MONEY?

We use a patented intelligent heating solution that can reduce power consumption by more than 30% compared to machines of other factories.

Our patented automatic mode can control three machines by one person, and the saved electricity bills and workers' wages can be purchased for one new machine in one month. Our powder shake is double intelligent temperature control heating lamp(Baked Front And Back), 4KW/ hour.

Compared with other company 60CM DTF Printer Machine, saing 76.56$ per month.



FAQ

1. How long i can get the feedback after we sent the enquiry?

We will reply you within 12 hours in working day.



2. Can you do our design?

Yes, we are source factory. Your customized design (OEM/ODM) is available.



3. Can you make our design for the package?

Yes, pls send us the design file, we will value the price and make the exact same package basing on your design. Or we also have some package for your reference.



4. What's the universal lead-time for order delivery?

Small production: 3-4 days Mass production :7-15days or basing on your qty.



5. What kind of shipping do you have?

DHL,FEDEX,UPS,EMS,TNT,etc.



9 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads 09 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads 19 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads 29 Colors A2 DTF Printer CMYK+LC+LM+Neon Y+Neon M+W Double EPSON I3200 Heads 3



About US&After-sale service

1. Inquiry for professional quotation and patient communication.

2. Confirm the price, lead time, sample, payment term etc to complete orders.

3. DGsupercolor Sales will give you the PROFORMA INVOICE to you with details.

4. Customers make the payment for deposit via aliexpress,TT, West Union or Paypal.

5. Initial production will be arranged in terms of the lead time, we will inform customers in first time if any uncertain matters will happen, adjust the new lead time.

6. Middle production will keep you informed for the latest updates.

7. Customer make the payment for the balance before shipping.

8. End production will give you the tracking after arrange the shipment. If you need more and shipping by sea, we will also give you the photo for approval.

9. Order can be said “finish” when you receive the goods and satisfy with them and our service.


What is the difference between DTF and DTG?
In DTG, the drawing and ink are mixed with the fabric and feel rougher to the touch, like the base itself, while in DTF, the fixer makes it feel plastic, brighter, and has less adhesion to the fabric.

Is the sublimation shirt okay?
The process is suitable for 100% cotton, cotton polyester blends, etc. While sublimation works with most 100% polyester materials, the inks perform better on lighter colors. If you are printing on a dark polyester shirt, your ink may look dull or faded due to the dark pigment in the shirt.



Is sublimation printing expensive?
Dye sublimation is affordable. Sublimation printing used to be expensive and daunting due to the variety of equipment and multi-step processes required. That's a whopping $20,000 for the printer alone, not including the cost of the heat press.

What does DTF mean in print?
Direct to Film(DTF), is a process that uses a hot pressing mechanism to transfer prints to fabric or other substrates. Unlike the DTG method, which is only applicable to cotton fabrics, DTF can be applied to cotton and polyester blends.



Why choose us

We have 8 years of independent R&D and production experience, the industry's rare self-developed board and three-year warranty, complete source factory. A number of industry-leading paper feeding and printing patent technologies. The outstanding features of our products are that they have great technical advantages and high quality, which can help customers save a lot of time and cost.
